Carbonated Drinks Mixing System
![Carbonated drinks mixing system](https://www.jmtings.com/wp-content/uploads/2021/08/Carbonated-drinks-mixing-system.jpg)
General Process Flow Chat
![碳酸饮料调配系统](https://www.jmtings.com/wp-content/uploads/2021/08/碳酸饮料调配系统-1024x449.jpg)
Solutions can be slightly diferent because the beverage kinds, production capacity, equipment quantity will be different. So it depands on customers’ actual situations.
Equipment and process introduction
![Sugar Melting Tank](https://www.jmtings.com/wp-content/uploads/2021/08/Sugar-Melting-Tank.jpg)
用料: 不锈钢304/316、镍含量不低于8%
功能: The device melts the sugar by heating and mixing water.
![juice pump1](https://www.jmtings.com/wp-content/uploads/2021/08/juice-pump1.jpg)
用料: Stainless Steel 304/ 316
功能: The device provides sufficient pressure for pumping juice from one device to the other.
![syrup filter 1](https://www.jmtings.com/wp-content/uploads/2021/08/syrup-filter-1.jpg)
用料: Stainless Steel 304/ 316
功能: The device filters the sugar that is not melted in the syrup from the sugar melting tank
.
![Mixing Tank 1](https://www.jmtings.com/wp-content/uploads/2021/08/Mixing-Tank-1.jpg)
用料: Stainless Steel 304/ 316
功能: Syrup, water and other materials are fully mixed in the mixing tank.
![Carbon Dioxide Purifier](https://www.jmtings.com/wp-content/uploads/2021/08/Carbon-Dioxide-Purifier.jpg)
用料: Stainless Steel 304/ 316
功能: The Device filters the carbon dioxide, so that no dust will entre the mixing system.
![Buffter tank or heat preserve tank](https://www.jmtings.com/wp-content/uploads/2021/08/Buffter-tank-or-heat-preserve-tank.jpg)
用料: Stainless Steel 304/ 316
功能: The device preserve the juice temperature with circulation of beverage flow.
![Carbon Dioxide and Drinks Mixing Machine](https://www.jmtings.com/wp-content/uploads/2021/08/Carbon-Dioxide-and-Drinks-Mixing-Machine.jpg)
用料: Stainless Steel 304/ 316
功能: This device mixes the beverage and carbon dioxide together.
![Heat Exchanging Device](https://www.jmtings.com/wp-content/uploads/2021/08/Heat-Exchanging-Device.jpg)
用料: Stainless Steel 304/ 316
功能: This device exchanges the temperature between the hot and chill bevergae, so as to make the heated beverage cool down slowly.
![CIP Cleaning System](https://www.jmtings.com/wp-content/uploads/2021/08/CIP-Cleaning-System.jpg)
用料: Stainless Steel 304/ 316
功能: The Machine is for cleaning the inner parts of all machine and tubing for the whole mixing system with detergent and high pressure water flow.
![working platform](https://www.jmtings.com/wp-content/uploads/2021/08/working-platform.jpg)
用料: Stainless Steel 304/ 316
功能: This platform is specially used for operating all equipment in the mixing system. It can be customized according to your requirement.
